ViewSonic VG3820C 38-inch WQHD+ Curved USB-C Business Monitor
Brian Long
Product Introduction
The ViewSonic VG3820C is a 38-inch-class curved ultrawide business monitor designed for professionals who want a large, continuous desktop for multitasking. Its 37.5-inch viewable IPS panel combines a 3840 x 1600 WQHD+ resolution, 21:9 aspect ratio, 2300R curvature, and 75Hz refresh rate, creating a spacious workspace for documents, spreadsheets, dashboards, development tools, timelines, and multiple applications.
USB-C provides video, audio, data, and up to 96W of laptop charging through a single cable. An integrated KVM switch and PIP/PBP functionality further expand the monitor’s multi-system capabilities, while dual HDMI 2.0 inputs, DisplayPort, USB connectivity, stereo speakers, and an ergonomic stand make the VG3820C a versatile centerpiece for professional desktop environments.
Product Gallery
Product Details
Key Features
-
38-inch-Class Ultrawide Workspace: The 37.5-inch viewable display provides a large continuous desktop that can reduce the need for separate side-by-side monitors.
-
3840 x 1600 WQHD+ Resolution: The expanded vertical resolution provides 160 additional vertical pixels compared with conventional 3440 x 1440 ultrawide monitors, creating additional room for documents, application controls, timelines, spreadsheets, and development environments.
-
21:9 Ultrawide Aspect Ratio: The wide display format provides approximately 35% more screen space than a comparable 16:9 display, making it well suited to side-by-side applications and multitasking.
-
IPS Panel Technology: IPS technology provides consistent image reproduction and wide 178° horizontal and vertical viewing angles.
-
2300R Curvature: The gentle curved design helps keep the edges of the expansive display within a comfortable viewing distance while preserving the benefits of a large continuous workspace.
-
75Hz Refresh Rate: A 75Hz refresh rate provides smoother cursor movement, scrolling, and general desktop interaction than conventional 60Hz displays.
-
300-Nit Brightness: Typical brightness of 300 cd/m² provides clear visibility for professional office, productivity, and multimedia applications.
-
2,000:1 Static Contrast Ratio: Enhanced native contrast provides stronger differentiation between dark and bright image areas than conventional 1,000:1 IPS displays.
-
1.07 Billion Colors: 10-bit color support through 8-bit + FRC processing provides smooth gradients and detailed color transitions.
-
Single-Cable USB-C Connectivity: Connect a compatible laptop through USB-C for display video, audio, USB data, and charging through one cable.
-
96W USB-C Power Delivery: The USB-C connection provides up to 96W of charging power to compatible laptops, reducing the need for a separate laptop power adapter at the desk.
-
Integrated KVM Switch: Built-in KVM functionality allows one keyboard, mouse, and display to control two connected computers, simplifying multi-system workstations.
-
Picture-by-Picture (PBP): Display content from two connected systems side by side on the same ultrawide screen.
-
Picture-in-Picture (PIP): View a secondary input in an inset window while continuing to work with the primary source.
-
Multi-System Productivity: KVM, PIP, and PBP functionality make the VG3820C particularly useful for professionals who regularly work between two computers.
-
Integrated USB Hub:
- 2x USB Type-A downstream ports
- 1x USB Type-B upstream port
- 1x USB Type-C connection with up to 96W power delivery
-
Versatile Video Connectivity:
- 1x USB Type-C with video, audio, data, and up to 96W charging
- 2x HDMI 2.0
- 1x DisplayPort
- 1x USB Type-B upstream
- 2x USB Type-A downstream
- 1x 3.5 mm audio output
-
Multiple Computer Inputs: Dual HDMI 2.0, DisplayPort, and USB-C connections provide flexibility for desktops, laptops, workstations, and other compatible sources.
-
Dual Integrated Speakers: Two 2.5W speakers provide built-in stereo audio for meetings, presentations, training, multimedia, and everyday desktop use.
-
Eye ProTech+: Flicker-Free technology and a blue-light filter help support comfortable viewing during extended work sessions.
-
130 mm Height Adjustment: The display can be raised or lowered through a 130 mm / 5.1-inch range.
-
60° Swivel: Side-to-side swivel adjustment helps position the expansive display for individual viewing or collaboration.
-
Adjustable Tilt: 5° forward and 15° backward tilt provide additional viewing-angle flexibility.
-
VESA Mount Compatible: Standard 100 x 100 mm VESA mounting supports compatible monitor arms and wall-mount systems.
-
Kensington Lock Slot: Supports compatible physical security cables for corporate, institutional, and shared workspaces.
-
Efficient Business Display: ViewSonic specifies typical display consumption of 34W, with optimized and conserve Eco modes available for lower-energy operation.
-
Three-Year Limited Warranty: Backed by ViewSonic’s three-year limited U.S. warranty on parts, labor, and backlight, subject to ViewSonic warranty terms.
Specifications
| Category | Specification | VG3820C |
|---|---|---|
| Display | Screen Size | 38" class |
| Viewable Area | 37.5" | |
| Panel Type | IPS | |
| Resolution | 3840 x 1600 WQHD+ | |
| Aspect Ratio | 21:9 | |
| Curvature | 2300R | |
| Refresh Rate | 75Hz | |
| Brightness | 300 cd/m² | |
| Static Contrast Ratio | 2,000:1 | |
| Dynamic Contrast Ratio | 50,000,000:1 | |
| Displayed Colors | 1.07 billion | |
| Color Support | 10-bit (8-bit + FRC) | |
| Response Time | 5ms typical GTG | |
| Viewing Angles | 178° horizontal / 178° vertical | |
| Backlight | LED | |
| Backlight Life | 30,000 hours | |
| Panel Surface | Anti-glare, 3H hard coating | |
| Resolution Support | Maximum PC Resolution | 3840 x 1600 |
| Maximum Mac Resolution | 3840 x 1600 | |
| Maximum Refresh Rate | 75Hz | |
| USB-C | USB Type-C | 1x |
| Video | Supported | |
| Audio | Supported | |
| USB Data | Supported | |
| Power Delivery | Up to 96W | |
| USB Connectivity | USB Type-A Downstream | 2x |
| USB Type-B Upstream | 1x | |
| Video Connectivity | HDMI | 2x HDMI 2.0 |
| DisplayPort Input | 1x | |
| DisplayPort Output | None | |
| USB-C Video | Yes | |
| Multi-System Features | Integrated KVM | Yes |
| Picture-by-Picture | Yes | |
| Picture-in-Picture | Yes | |
| Networking | RJ45 Ethernet | No |
| Audio | Internal Speakers | 2.5W x 2 |
| Audio Output | 1x 3.5 mm | |
| Input Signal | HDMI Horizontal Frequency | 15–222 kHz |
| DisplayPort Horizontal Frequency | 15–222 kHz | |
| USB-C Horizontal Frequency | 15–222 kHz | |
| HDMI Vertical Frequency | 30–75Hz | |
| DisplayPort / USB-C Vertical Frequency | 48–75Hz | |
| Eye Comfort | Flicker-Free | Yes |
| Blue Light Filter | Yes | |
| Ergonomics | Height Adjustment | 130 mm / 5.1" |
| Swivel | 60° | |
| Tilt | 5° forward / 15° backward | |
| Pivot | No | |
| Mounting & Security | VESA Mount | 100 x 100 mm |
| Kensington Lock Slot | Yes | |
| Power | Voltage | AC 100–240V, 50/60Hz |
| Power Supply | External | |
| Typical Consumption | 34W | |
| Maximum Consumption | 43W | |
| Eco Mode - Optimized | 30W | |
| Eco Mode - Conserve | 27W | |
| Standby | 0.5W | |
| Operating Conditions | Temperature | 32–104°F / 0–40°C |
| Humidity | 20–90%, non-condensing | |
| Dimensions | With Stand | 35.33" W x 14.85–19.96" H x 9.36" D |
| Without Stand | 35.33" W x 15.69" H x 4.17" D | |
| With Stand (Metric) | 897.5 W x 377.2–507.2 H x 237.8 D mm | |
| Without Stand (Metric) | 897.5 W x 398.5 H x 105.9 D mm | |
| Packaging | 45.3" W x 20.7" H x 7.5" D | |
| Packaging (Metric) | 1150 x 525 x 190 mm | |
| Weight | Net With Stand | 20.7 lb / 9.4 kg |
| Net Without Stand | 15.9 lb / 7.2 kg | |
| Gross | 29.3 lb / 13.3 kg | |
| Certifications | ENERGY STAR | Certified |
| Additional Regulations | cTUVus, FCC-B, ICES003 | |
| Warranty | U.S. Limited Warranty | 3 years on parts, labor, and backlight |
Included in the Box
- ViewSonic VG3820C monitor
- Ergonomic stand
- 3-pin power cable
- AC/DC power adapter
- HDMI cable
- DisplayPort cable
- USB-C cable
- USB Type-A to Type-B cable
- Quick Start Guide
38-inch WQHD+ Productivity Workspace
The VG3820C provides a large continuous 3840 x 1600 desktop that can take the place of some conventional dual-monitor configurations.
Typical workflows include:
- Displaying multiple business applications side by side
- Working with large spreadsheets and financial models
- Comparing documents and reference material
- Viewing dashboards and analytics
- Managing project timelines
- Working with development tools and code
- Editing wide creative timelines
- Keeping communications visible alongside primary work
- Monitoring multiple applications without a bezel dividing the workspace
The additional 160 vertical pixels compared with a 3440 x 1440 ultrawide display provide extra room for application interfaces, documents, spreadsheets, and browser content.
2300R Curved IPS Display
The VG3820C uses a relatively gentle 2300R curvature rather than the more aggressive curves found on some smaller ultrawide monitors.
This design helps:
- Keep the outer edges of the 37.5-inch panel within a comfortable viewing distance.
- Maintain the benefits of a large continuous desktop.
- Reduce the need to turn toward separate physical displays.
- Create an expansive workspace without a center bezel.
- Preserve wide IPS viewing angles for shared content and collaboration.
USB-C Workstation
The VG3820C simplifies compatible laptop workstations through a single USB-C connection.
- Connect a compatible laptop using one USB-C cable.
- Carry 3840 x 1600 display video over the same connection.
- Transfer audio and USB data.
- Deliver up to 96W of charging power to the connected laptop.
- Connect a keyboard, mouse, storage device, or other peripherals through the integrated USB hub.
- Connect additional computers through DisplayPort or either HDMI 2.0 input.
Integrated KVM for Two Computers
The built-in KVM switch is particularly useful for users who alternate between two computers at the same desk.
A typical setup can include:
- A laptop connected through USB-C.
- A desktop or secondary computer connected through another video input and USB upstream connection.
- A keyboard and mouse connected to the monitor’s USB hub.
- The monitor’s KVM function used to switch the connected USB peripherals between systems.
This arrangement allows the same display, keyboard, and mouse to be shared without maintaining duplicate desktop peripherals.
PIP and PBP Multitasking
The VG3820C can display content from multiple connected sources through Picture-in-Picture and Picture-by-Picture modes.
Picture-by-Picture (PBP) can place content from two systems beside each other on the 21:9 screen. This can be useful for:
- Comparing information between two computers
- Monitoring a secondary system
- Working between corporate and personal devices
- Comparing development environments
- Reviewing source and output systems simultaneously
Picture-in-Picture (PIP) places a secondary source within an inset window over the primary source, allowing another system or feed to remain visible without dividing the entire workspace.
Business and Professional Applications
The VG3820C is particularly well suited for:
- Executive workspaces
- Financial and spreadsheet-intensive work
- Data analysis and dashboards
- Software development
- Project management
- Corporate home offices
- Laptop-based professional workstations
- Multi-computer workspaces
- Content timelines and production management
- Professionals replacing a conventional dual-monitor setup
- Users who benefit from PIP/PBP and integrated KVM control
Manuals and Documents
-
ViewSonic VG3820C U.S. Product Datasheet - Manufacturer product sheet covering the 38-inch WQHD+ IPS display, 2300R curvature, 96W USB-C, KVM functionality, connectivity, ergonomics, dimensions, power consumption, and warranty.
-
ViewSonic VG3820C Global Product Page - Manufacturer overview covering the WQHD+ ultrawide panel, USB-C workstation functionality, USB hub, 75Hz refresh rate, Eye ProTech+, and ergonomic design.
-
ViewSonic VG3820C U.S. Product Page - Current U.S. manufacturer product information, specifications, KVM and PIP/PBP features, package contents, downloads, and warranty information.
-
ViewSonic VG3820C Business Product Page - Current ViewSonic business product information and support resources.
The ViewSonic VG3820C combines a large 37.5-inch 3840 x 1600 IPS workspace with a gentle 2300R curve, 75Hz performance, 96W USB-C charging, and flexible multi-system functionality. Its integrated KVM, PIP/PBP modes, dual HDMI inputs, DisplayPort, USB hub, ergonomic stand, and expansive 21:9 format make it particularly well suited to business professionals who want to consolidate a multi-application or multi-computer workspace onto one continuous ultrawide display.
