ViewSonic VG2457V 24-inch Full HD Video Conferencing Docking Monitor

Key Features

• 24-inch Full HD Business Display: The 23.8-inch panel provides 1920 x 1080 resolution for office productivity, communications, documents, spreadsheets, and everyday professional applications.

• 100Hz Refresh Rate: A refresh rate of up to 100Hz provides smoother scrolling, cursor movement, window transitions, and general desktop interaction than conventional 60Hz office displays.

• Zoom-Certified 5MP Pop-Up Webcam: The integrated high-resolution camera provides professional video conferencing without requiring a separate desktop webcam.

• Retractable Privacy Design: The webcam retracts into the monitor when it is not needed, providing a simple physical privacy mechanism.

• Windows Hello Facial Recognition: Integrated IR functionality supports Windows Hello for fast, password-free facial authentication on compatible Windows systems.

• Integrated LED Fill Lights: Adjustable lighting around the webcam helps improve facial illumination during video meetings and calls.

• Integrated Microphone: A built-in microphone simplifies conferencing and reduces the need for additional desktop audio hardware.

• Front-Facing 5W Speakers: Integrated speakers are positioned for clear conferencing, presentation, training, and everyday desktop audio.

• Single-Cable USB-C Docking: Connect a compatible laptop through USB-C for video, audio, USB data, networking access, and charging through a streamlined workstation connection.

• 90W USB-C Power Delivery: The primary USB-C connection supplies up to 90W of charging power to compatible laptops.

• 15W USB-C Quick Charging: A secondary USB-C connection provides up to 15W for compatible smartphones, tablets, and other mobile devices.

• Integrated Ethernet: Built-in RJ45 connectivity provides wired networking through the monitor’s docking environment.

• DisplayPort Daisy Chaining: A dedicated DisplayPort output supports MST daisy chaining for compatible Windows systems and graphics hardware.

• Streamlined Multi-Monitor Workstations: Connect a compatible computer to the VG2457V through USB-C or DisplayPort and use DisplayPort-out to extend the desktop to an additional compatible display.

• Integrated USB Hub: USB downstream connectivity provides convenient connections for keyboards, mice, storage, headsets, and other professional peripherals.

• Flexible Connectivity:

  • USB-C upstream with DisplayPort Alt Mode and up to 90W power delivery
  • Secondary USB-C with data and up to 15W charging
  • HDMI
  • DisplayPort input
  • DisplayPort output
  • RJ45 Ethernet
  • USB downstream ports
  • 3.5 mm audio output

• Eye ProTech+: Flicker-Free and low-blue-light technologies help support comfortable viewing during extended work sessions.

• Fully Ergonomic Stand: Height, tilt, swivel, and pivot adjustments allow the display to be positioned for individual workstations, hot desks, and shared environments.

• Portrait Orientation: Pivot adjustment supports portrait-oriented documents, coding, communications, and other vertically oriented content.

• Anti-Glare Surface: A 3H hard-coated anti-glare display surface with 25% haze helps reduce distracting reflections.

• VESA Mount Compatible: Standard 100 x 100 mm VESA mounting supports compatible monitor arms, wall mounts, and multi-display mounting systems.

• Integrated Docking Station Design: Video, laptop charging, Ethernet, peripherals, conferencing hardware, and multi-monitor expansion are consolidated into a single desktop display.

Specifications

Included in the Box

• ViewSonic VG2457V monitor
• Ergonomic stand
• Power cord
• Video cable
• USB cable
• Quick Start Guide

Integrated Video Conferencing

The VG2457V combines the primary hardware required for professional video meetings directly into the monitor.

• Use the integrated 5MP pop-up webcam for high-resolution video conferencing.
• Sign in to compatible Windows systems using Windows Hello facial recognition.
• Adjust the integrated LED fill lights to improve facial illumination.
• Use the integrated microphone for voice capture.
• Listen through the front-facing 5W speakers.
• Retract the webcam into the display when it is not needed.
• Use Zoom-certified camera functionality for supported Zoom workflows.

USB-C Docking Workstation

The VG2457V can serve as the central connectivity hub for a compatible laptop-based workspace.

• Connect a laptop using a single USB-C cable.
• Carry display video, audio, and USB data over the same connection.
• Deliver up to 90W of charging power to a compatible laptop.
• Access a wired network through the integrated RJ45 connection.
• Connect keyboards, mice, storage devices, headsets, and other peripherals through the integrated USB hub.
• Charge a compatible mobile device through the secondary USB-C port at up to 15W.
• Connect additional video sources through HDMI or DisplayPort.

DisplayPort Daisy Chaining

Unlike ViewSonic conferencing monitors that provide display inputs only, the VG2457V includes a dedicated DisplayPort output for MST-based multi-monitor configurations.

A typical configuration can use:

1. A compatible Windows PC connected to the VG2457V through USB-C or DisplayPort.
2. The VG2457V as the primary conferencing and docking display.
3. DisplayPort-out from the VG2457V connected to a second compatible monitor.

For 1920 x 1080 operation at 100Hz on the VG2457V itself, ViewSonic specifies that DisplayPort MST should be disabled. Multi-monitor resolution and refresh-rate combinations depend on the connected computer, graphics hardware, interface bandwidth, and display configuration.

Note: macOS does not support DisplayPort MST extended-desktop daisy chaining in the same manner as Windows. Mac users should use an appropriate Thunderbolt or direct multi-display configuration when multiple independent external displays are required.

Business and Hybrid-Work Applications

The VG2457V is particularly well suited for:

• Corporate offices
• Hybrid and remote work
• Video-conferencing workstations
• Zoom meeting environments
• Windows Hello-enabled workstations
• Laptop hot desks
• Flexible and shared workspaces
• Home offices
• Multi-monitor office configurations
• Call center and communications environments
• Business users seeking integrated docking and conferencing hardware

Manuals and Documents

• ViewSonic VG2457V Product Datasheet - Manufacturer product overview covering the Full HD 100Hz display, Zoom-certified webcam, Windows Hello, USB-C docking, Ethernet, daisy chaining, and conferencing features.

• ViewSonic VG2457V Online User Guide - Manufacturer operating documentation covering installation, USB-C connectivity, DisplayPort MST, webcam functionality, monitor configuration, and maintenance.

• ViewSonic VG2457V Technical Specifications - Detailed manufacturer specifications covering supported resolutions and timings, dimensions, VESA mounting, operating conditions, and power requirements.

• ViewSonic VG2457V Business Product Page - Current ViewSonic business product information, specifications, downloads, and support resources.
